EVI-D70P Sony 18X PTZ Camera

Intelligent communication to capture remotely every scene

The EVI-D70P combine a high quality colour video camera with the flexibility of a remote pan/tilt/zoom operation, all in a compact easy-to-use package. Incorporating an 18x optical zoom lens, these cameras allow a user to zoom in on a small or distant object with exceptionnal clarity.

Compared to his predecessor, the EVI-D31, the EVI-D70P camera offer a wide pan/tilt range, and a faster pan/tilt mechanism.
Above all, these cameras are ceiling mountable - a first for the popular Sony EVI cameras.

The EVI-D70P is equiped with a variety of convenient features such as auto ICR function, Alarm function and RS-232C/422 serial control , making them ideal for any remote shooting applications such as distance learning, indoor and outdoor security systems, courtrooms, event venues, concert halls, and more.

  • Ceiling/Desktop mountable:

    The new EVI-D70P camera is at the same time ceiling mountable and desktop, what represent a unique feature in this Pan Tilt Zoom market. In addition, a complete ceiling kit is provided with the camera.

  • Superb picture quality with Exview HAD CCD:

    The adoption of Sony Exview had CCD improves basic camera performance. For example, these cameras offer superb sensitivity of 1 lux (typical), and a low smear level and D-range.

  • Auto ICR (IR Cut Filer Removal) Function:

    The Auto ICR function automatically switches the settings to attach or remove the IR Cut filter is automatically disabled (ICR ON), and tghed infrazred sensitivity is increased. With a set level of brightness, the filter is automatically engageds depending on the ambient light, allowing the cameras to be effective both in day and night environments.

  • RS-232C or RS-422 Serial control (VISCA Command):

    All cameras settings and pan/tilt/zoom functiolns can be con btrolled remotely via a PC. With the RS-232C connection , maximum cable lengh can be extented to 15 meters, while the RS-422 connection extends this further to 1200 meters.

Technical Specifications

Please be aware that the features/specifications can differ from country to country

Collapse allExpand all


Generic Specifications

Video Signal PAL
Image Sensor 1/4"Exview HAD Color CCD
Effective Pixels 752 (H) x 585 (V)
H. Resolution 460 TV lines
Lens X18 Power Zoom, f=4.1mm to 73.8 mm, F1.8 to F3.0
H. Angle of View 2.7° to 48 degrees
Shortest Subject Distance 10mm (wide end), 800mm (Tele end)
Minimum Illumination 1lx (F1.4)
Auto Exposure Auto/Manual/Priority AE, Exposure compensation, Back-light compensation
Shutter Speed 1 to 1/10,000 s
Gain Auto/ATW/Indoor/Outdoor/One Push/Manual
White Balance ATW/One Push Hold, Indoor Preset, Outdoor Preset(VISCA TM control)
S/N Ratio more than 50dB
Pan/Tilt Pan: -170° to +170° ( Max. speed: 100°/s), Tilt: -30° to 90° (Max. speed: 90°/s)
Video Output VBS, Y/C
Control Terminal RS-232C (8 pin mini DIN)/RS-422 (9-pin) control (VISCA)
Baud rate: 9.6 Kb/s, 38.4 Kb/s
Power Requirement DC 10.8 to 13.2 V
Power Consumption 12 W
Operating Temperature 0 to 40 ° C (32 to 40°F)
Storage Temperature -20 to 60 ° C (-4 to 140°F)
Dimensions (W x H x D) 132 x 144 x 144 mm
Mass 950 g


Supplied Accessories

AC power adapter (x 1)
Operation manual (x 1)
Remote Commander (x 1)
Velcro Tape
